19. LIGHTS SWITCHES/ FUEL PUMP
SERVICE INFORMATION
GENERAL
Note the following when replacing the halogen headlight bulb
Wear clean gloves while replacing the bulb. Do not put finger prints on the headlight bulb,
as they may create hot spots on the bulb and cause it to fail.
If you touch the bulb with your bare hands, clean it with a cloth moistened with alcohol to
prevent its early failure.
Be sure to install the dust cover after replacing the bulb.
Check the battery condition before performing any inspection that requires proper battery voltage.
A continuity test can be made with the switches installed on the scooter.
Route the wires and cables properly after servicing each component.
TROUBLESHOOTING
Lights do not come on when ignition Temperature gauge does not register
switch is “ON” correctly
Burned bulb Faulty temperature gauge
Faulty switch Faulty thermosensor
Poorly connected, broken or shorted wire Broken or shorted wire between
the temperature gauge and thermosensor
Fuel gauge does not work or
wrong show figures
Faulty fuel gauge
Faulty fuel unit
Poorly connected wire between fuel
gauge and fuel unit
Fuse burned out
SPECIFICATIONS
Fuse 10A,15A,30A
Headlight bulb 12V 35W/35W *2
Turn signal light bulb 12V 21W(Front) / 10W(Rear)
Stoplight/taillight 12V 21/5W
A halogen head light bulb becomes very hot while the head light is on, and remains for a while
after it is turned off. Be sure to let it cool down before servicing.
