Kyocera ECOSYS FS-6525MFP Technical Reference Manual

Chapter 7 Emulation
7-58
Raster Graphics
Raster
Resolution
75 dots/inch
ESC
*t75R 1B 2A 74 37 35
52
YesYesYesYesYes
100 dots/inch
ESC
*t100R 1B 2A 74 31 30
30 52
YesYesYesYesYes
150 dots/inch
ESC
*t150R 1B 2A 74 31 35
30 52
YesYesYesYesYes
200 dots/inch
ESC
*t200R 1B 2A 74 32 30
30 52
No Yes No Yes Ye s
300 dots/inch
ESC
*t300R 1B 2A 74 33 30
30 52
YesYesYesYesYes
600 dots/inch
ESC
*t600R 1B 2A 74 36 30
30 52
No Yes No Yes Yes
Orientation
Raster Graphics
Raster
Graphics
Presentation
Follows
orientation
ESC
*r0F 1B 2A 72 30 46 Yes Yes Yes Yes Yes
Follows
physical page
ESC
*r3F 1B 2A 72 33 46 Yes Yes Yes Yes Yes
Start Raster
Graphics
Left Raster
Graphics
Margin
ESC
*r0A 1B 2A 72 30 41 Yes Yes Yes Yes Yes
Current
Cursor
ESC
*r1A 1B 2A 72 31 41 Yes Yes Yes Yes Yes
Scale mode
(logical left
page
boundary)
ESC
*r2A 1B 2A 72 32 41 No No No No Yes
Scale mode
(at CAP)
ESC
*r3A 1B 2A 72 33 42 No No No No Yes
Raster Y
Offset
# of Raster
Lines of
vertical
movement
ESC
*b#Y 1B 2A 62 #...#
59
YesYesYesYesYes
Set Raster
Compression
Mode
Unencoded
ESC
*b0M 1B 2A 62 30 4D Yes Yes Yes Yes Yes
Run-Length
Encoded
ESC
*b1M 1B 2A 62 31 4D Yes Yes Yes Yes Yes
Tagged Image
File Format
ESC
*b2M 1B 2A 62 32 4D Yes Yes Yes Yes Yes
Delta Row
ESC
*b3M 1B 2A 62 33 4D Yes Yes Yes Yes Yes
Adaptive
compression
ESC
*b5M 1B 2A 62 35 4D Yes Yes Yes Yes Yes
Replacement
Delta Row
ESC
*b9M 1B 2A 98 39 4D Yes Yes Yes Yes Yes
Transfer
Raster Da
ta by
row
# of Bytes
ESC
*b#W
[Data]
1B 2A 62 #...#
57
YesYesYesYesYes
Transfer
Raster Data
(by plane)
# of Bytes
ESC
*b#V
[Data]
1B 2A 98 #...#
56
No No No No Yes
End Raster
Graphics
Old version
ESC*
rB 1B 2A 72 42 Yes Yes Yes Yes Yes
Preferred
ESC
*rC 1B 2A 72 43 Yes Yes Yes Yes Yes
Raster Height
(Source)
# Raster Rows
ESC
*r#T 1B 2A 72 #...#
54
YesYesYesYesYes
Raster Width
(Source)
# Pixels of the
Specified
Resolution
ESC
*r#S 1B 2A 72 #...#
53
YesYesYesYesYes
THE PRINT MODEL
Imaging
Table 7.25. HP LaserJet PCL Commands (Sheet 10 of 15)
Function Parameter Command Hexadecimal
Value
1000
1000+
1800
1900
3800
6300
6750
6900
9100DN
9500DN
8000C
