Page #332 background imageLoading...
Page #332 background image
10-9
Troubleshooting > Troubleshooting
Troubleshooting
Solving Malfunctions
The table below provides general guidelines for problem solving.
If a problem occurs with your machine, look into the checkpoints and perform procedures indicated on the following
pages. If the problem persists, contact your Service Representative.
Machine Operation Trouble
When the following machine operation troubles occur, implement appropriate procedures.
NOTE
When contacting us, the serial number will be necessary.
To check the serial number, refer to the following:
Checking the Equipment's Serial Number (page i)
Symptom Checkpoints Corrective Actions
Reference
Page
The screen does not
respond when the power
switch is turned on.
Check the power cable. Connect both ends of the power cable
securely.
page 2-9
Pressing the [Start] key
does not produce copies.
Is there a message on the screen? Determine the appropriate response to
the message and respond accordingly.
page 10-19
Is the machine in Sleep mode? Select the [Energy Saver] key. page 2-29
Blank sheets are ejected. Are the originals loaded correctly? When placing originals on the platen,
place them face-down and align them
with the original size indicator plates.
page 5-2
When placing originals in the document
processor, place them face-up.
page 5-3
Check that the settings of the
application software.
Paper often jams. Is the paper loaded correctly? Load the paper correctly. page 3-4
Turn the orientation 180 degrees around
in which the paper is positioned.
page 3-4
Is the paper of the supported type? Is it
in good condition?
Remove the paper, turn it over, and
reload it.
page 3-4
Is the paper curled, folded or wrinkled? Replace the paper with new paper. page 3-4
Are there any loose scraps or jammed
paper in the machine?
Remove any jammed paper. page 10-35
2 or more sheets are
overlaps when ejected.
(multi feed)
Load the paper correctly. page 3-2

Table of Contents

Other manuals for Kyocera ECOSYS MA2100cwfx

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS MA2100cwfx and is the answer not in the manual?

Kyocera ECOSYS MA2100cwfx Specifications

General IconGeneral
N-up printing2, 4, 6, 8, 9, 16, 25
Duplex printingYes
Print technologyLaser
Duplex printing modeAuto
Booklet printing functionNo
Time to first page (black, normal)11 s
Time to first page (color, normal)12.5 s
Print speed (black, normal quality, A4/US Letter)21 ppm
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A4)21 cpm
Scan toE-mail, FTP, SMB, TWAIN, USB, WIA
Scanner typeFlatbed & ADF scanner
Scan speed (black)30 ppm
Scan speed (color)23 ppm
Image formats supportedJPEG, TIFF
Document formats supportedPDF, XPS
FaxingMono faxing
Modem speed33.6 Kbit/s
Fax resolution (black)400 x 400 DPI
Fax transmission speed2 sec/page
Printer fontsPCL, PostScript
Printing colorsBlack, Cyan, Magenta, Yellow
Duplex functionsPrint
Country of originChina
Maximum duty cycle65000 pages per month
Recommended duty cycle500 - 1500 pages per month
Replacement cartridgesTK-5430K Zwart (toner 1.250) ISO/IEC 19798 TK-5430Y Geel (toner 1.250) ISO/IEC 19798 TK-5430M Magenta (toner 1.250) ISO/IEC 19798 TK-5430C Cyaan (toner 1.250) ISO/IEC 19798 TK-5440K Zwart (toner 2.800) ISO/IEC 19798 TK-5440Y Geel (toner 2.400) ISO/IEC 19798 TK-5440M Magenta (toner 2.400) ISO/IEC 19798 TK-5440C Cyaan (toner 2.400) ISO/IEC 19798
Number of print cartridges4
Page description languagesPCL 6, PDF, PostScript 3, XPS
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity550 sheets
Paper tray 1 input capacity250 sheets
Total number of input trays2
Maximum number of input trays3
Multi-Purpose tray input capacity50 sheets
Maximum print size216 x 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesLegal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-Purpose Tray media weight60 - 220 g/m²
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesKyocera Mobile Print
Processor familyARM Cortex-A9
Compatible memory cardsSD, SDHC
Maximum internal memory1536 MB
Sound pressure level (standby)30 dB
Sound pressure level (printing)48 dB
DisplayLCD
Control typeButtons
Product colorBlack, White
Market positioningHome & office
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1062 W
Power consumption (off)0.2 W
Power consumption (ready)41 W
Power consumption (sleep)1 W
Power consumption (printing)345 W
Energy Star Typical Electricity Consumption (TEC)0.73 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Package depth567 mm
Package width592 mm
Package height637 mm
Package weight33000 g
Cables includedAC
Included cartridge capacity (black)1500 pages
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth429 mm
Width417 mm
Height495 mm
