Kyocera ECOSYS MA2100cwfx User Manual

10-28
Troubleshooting > Troubleshooting
1105 Failed to send via SMB. Select [On] of the SMB settings on the Command
Center RX.
page 8-12
Failed to send the e-mail. Select [On] of the SMTP settings on the Command
Center RX.
page 2-54
Failed to send via FTP. Select [On] of the FTP settings on the Command
Center RX.
page 8-11
1106 Failed to send the e-mail. Check the sender address of SMTP on the Command
Center RX.
page 2-54
1131 Failed to send via FTP. Select [On] of the secure protocol settings on the
Command Center RX.
page 8-15
1132 Failed to send the e-mail. Check the following of the SMTP server.
• Is SMTP over SSL available?
• Is the encryption available?
Refer to the
Command
Center RX
User Guide.
Failed to send via FTP. Check the following of the FTP server.
• Is FTPS available?
• Is the encryption available?
—
2101 Failed to send via SMB. Check the network and SMB settings.
• The network cable is connected.
• The hub is not operating properly.
• The server is not operating properly.
• Host name and IP address
• Port number
—
Failed to send via FTP. Check the network and FTP settings.
• The network cable is connected.
• The hub is not operating properly.
• The server is not operating properly.
• Host name and IP address
• Port number
—
Failed to send the e-mail. Check the network and Command Center RX.
• The network cable is connected.
• The hub is not operating properly.
• The server is not operating properly.
• POP3 server name of the POP3 user
• SMTP server name
page 2-54
Error
Code
Message Corrective Actions
Reference
Page

Kyocera ECOSYS MA2100cwfx Specifications

General

N-up printing	2, 4, 6, 8, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Duplex printing mode	Auto
Booklet printing function	No
Time to first page (black, normal)	11 s
Time to first page (color, normal)	12.5 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	21 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scanner type	Flatbed & ADF scanner
Scan speed (black)	30 ppm
Scan speed (color)	23 ppm
Image formats supported	JPEG, TIFF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	2 sec/page
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Country of origin	China
Maximum duty cycle	65000 pages per month
Recommended duty cycle	500 - 1500 pages per month
Replacement cartridges	TK-5430K Zwart (toner 1.250) ISO/IEC 19798 TK-5430Y Geel (toner 1.250) ISO/IEC 19798 TK-5430M Magenta (toner 1.250) ISO/IEC 19798 TK-5430C Cyaan (toner 1.250) ISO/IEC 19798 TK-5440K Zwart (toner 2.800) ISO/IEC 19798 TK-5440Y Geel (toner 2.400) ISO/IEC 19798 TK-5440M Magenta (toner 2.400) ISO/IEC 19798 TK-5440C Cyaan (toner 2.400) ISO/IEC 19798
Number of print cartridges	4
Page description languages	PCL 6, PDF, PostScript 3, XPS
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Processor family	ARM Cortex-A9
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound pressure level (standby)	30 dB
Sound pressure level (printing)	48 dB
Display	LCD
Control type	Buttons
Product color	Black, White
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1062 W
Power consumption (off)	0.2 W
Power consumption (ready)	41 W
Power consumption (sleep)	1 W
Power consumption (printing)	345 W
Energy Star Typical Electricity Consumption (TEC)	0.73 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Package depth	567 mm
Package width	592 mm
Package height	637 mm
Package weight	33000 g
Cables included	AC
Included cartridge capacity (black)	1500 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	429 mm
Width	417 mm
Height	495 mm
