Machine Parts
Internal Components
1 Top Cover
2 Toner Container
3 Lock Lever
4 Front Cover
5 Duplex Front Cover
6 Developer Unit
7 Registration Roller
8 Paper Width Guides
9 Paper Width Adjusting Tab
10 Paper Length Guide
11 Paper Length Adjusting Tab
12 Paper Size Dial
