Kyocera ECOSYS P4035dn

2P7/2R0/3PN
1-5-36
23. Release the wires and FFC from hooks.
24. Release the fixing hook and thenre-
move the wire guide.
Figure 1-5-65
25. Remove three screws and then remove
the controller box cover.
Figure 1-5-66
Wire guide
Fixing hook
Hook
FFC
Hooks
Wire
Controller box cover
Screw
Screw
Screw
