2P7/2R0/3PN

1-6-3

1-6-2 Remarks on PWB replacement

(1) Engine PWB

NOTE: When replacing the PWB, remove the

EEPROM (U21) from the PWB and then reat-

tach it to the new PWB.

Figure 1-6-3

EEPROM(U21)

Engine PWB
