Kyocera ECOSYS P6021cdn Service Manual

2KT/2KV
2-3-5
YC8 1 +24V1 I 24 V DC 24 V DC power from RYPWB
Connected to
relay PWB
2 GND - - Ground
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 +24V3 O 24 V DC 24 V DC power from RYPWB
7 +24V3 O 24 V DC 24 V DC power from RYPWB
8 +24V3 O 24 V DC 24 V DC power from RYPWB
9 +24V3 O 24 V DC 24 V DC power from RYPWB
10 GND - - Ground
11 SLEEPN O 0/3.3 V DC Sleep mode signal: On/Off
12 PSSLEEPN O 0/3.3 V DC Sleep mode signal: On/Off
13 N.C. - - Not used
14 +3.3V2 I 3.3 V DC 3.3 V DC power from RYPWB
YC9 1
TCOVOPN
O 0/3.3 V DC TTSW: On/Off
Connected to
relay PWB
2 N.C. - - Not used
3 ZCROSS I 0/3.3 V DC (pulse) Zero-cross signal
4 RELAY O 0/3.3 V DC Power relay signal
5 HEATRE1 O 0/3.3 V DC FH: On/Off
6 (HEATRE2) - - Not used
7 VSYNC O 0/3.3 V DC Vertical synchronizing signal
8 EGIRN O 0/3.3 V DC Engine interruption signal
9 SBSY O 0/3.3 V DC Serial busy signal
10 SDIR O 0/3.3 V DC Serial communication direction change
signal
11 SI I 0/3.3 V DC (pulse) Serial communication data signal input
12 SO O 0/3.3 V DC (pulse) Serial communication data signal output
13 SCKN I 0/3.3 V DC (pulse) Serial communication clock signal
14 RESETN I 0/3.3 V DC Reset signal
15 I2CSCL I 0/3.3 V DC (pulse) EEPROM clock signal
16 GND - - Ground
17 I2CSDA I/O 0/3.3 V DC (pulse) EEPROM data signal
18 MPFJAM I 0/3.3 V DC MPFS: On/Off
19 +3.3V2 O 3.3 V DC 3.3 V DC power to RYPWB
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P6021cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	550 sheets
Total output capacity	- sheets
Maximum input capacity	1300 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound pressure level (printing)	48.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	61 W
Power consumption (printing)	353 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
