Kyocera ECOSYS P6021cdn Service Manual

2KT/2KV
2-3-14
Connector Pin Signal I/O Voltage Description
YC2-1 1 CT O 3.3 V DC 3.3 V DC power output
Connected to
ethernet
2 TD+ O 0/3.3 V DC (pulse) Transmission data
3 TD- O 0/3.3 V DC (pulse) Transmission data
4 RD+ I 0/3.3 V DC (pulse) Received data
5 RD- I 0/3.3 V DC (pulse) Received data
6 CT O 3.3 V DC 3.3 V DC power output
7 CAT PHY O 0/3.3 V DC Control signal
8 ANO PHY O 3.3 V DC 3.3 V DC power output
9 CAT MAC - - Ground
10 ANO MAC O 0/3.3 V DC Control signal
YC2-2 U1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
U2 DATA- I/O - USB data signal
U3 DATA+ I/O - USB data signal
U4 GND - - Ground
YC4 1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
2 DATAN I/O - USB data signal
3 DATAP I/O - USB data signal
4 GND - - Ground
5 GND - - Ground
YC5 1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 GND - - Ground
YC6 1 GND - - Ground
Connected to
laser scanner
unit CY
2 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-Y
3 PDYN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
4 VDOYP O LVDS APCPWB-Y video data signal (+)
5 VDOYN O LVDS APCPWB-Y video data signal (-)
6 GND - - Ground
7 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-C
8 PDCN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
9 VDOCP O LVDS APCPWB-C video data signal (+)
10 VDOCN O LVDS APCPWB-C video data signal (-)

Kyocera ECOSYS P6021cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	550 sheets
Total output capacity	- sheets
Maximum input capacity	1300 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound pressure level (printing)	48.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	61 W
Power consumption (printing)	353 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
