Kyocera ECOSYS P6021cdn Service Manual

2KT/2KV
1-3-6
Service items Description
No. Description Supplement
(22) Mac address -
(23) The last sent date and time -
(24) Transmission address -
(25) Destination information -
(26) Area information -
(27) Margin settings Top margin/Left margin
(28) Top offset for each paper source MP tray/Paper feeder 1/Paper feeder 2/
Paper feeder 3/Duplex/Page rotation
(29) Left offset for each paper source MP tray/Paper feeder 1/Paper feeder 2/
Paper feeder 3/Duplex/Page rotation
(30) Margin/Page length/Page width
settings
Top margin integer part/Top margin decimal part/
Left margin integer part/Left margin decimal part/
Page length integer part/Page length decimal part/
Page width integer part/Page width decimal part
(31) Life counter (The first line) Machine life/MP tray/Cassette/Paper feeder 1/
Paper feeder 2/Paper feeder 3/Duplex
Life counter (The second line) Drum unit K/Drum unit C/Drum unit M/Drum unit Y/
Intermediate transfer unit/Developing unit K/
Developing unit C/Developing unit M/
Developing unit Y/Maintenance kit
(32) Panel lock information 0: OFF/1: Partial lock/2: Full lock
(33) USB information U00: Not installed/U01: Full speed/U02: Hi speed
(34) Paper handling information 0: Paper source unit select/1: Paper source unit
(35) Color printing double count
mode
0: All single counts
3: Folio, Single count, Less than 330 mm (length)
(36) Black and white printing double
count mode
0: All single counts
3: Folio, Single count, Less than 330 mm (length)
(37) Billing counting timing -
(38) Temperature (machine inside) -
(39) Temperature (machine outside) -
(40) Relative temperature
(machine outside)
-
(41) Absolute temperature
(machine outside)
-
(42) Fixed assets number -
(43) Job end judgment time-out time -
(44) Job end detection mode -

Kyocera ECOSYS P6021cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	550 sheets
Total output capacity	- sheets
Maximum input capacity	1300 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound pressure level (printing)	48.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	61 W
Power consumption (printing)	353 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
