Kyocera ECOSYS P6021cdn Service Manual

2KT/2KV
1-3-18
Service items Description
No. Items Description
(7)
cont.
Paper Jam
Log
1620: PF feed sensor 2 is turned ON
1820: PF feed sensor 3 is turned ON
4002: Registration sensor does not turn ON (Paper feeder 1)
4003: Registration sensor does not turn ON (Paper feeder 2)
4009: Registration sensor does not turn ON (MP tray)
4012: Registration sensor does not turn OFF (Paper feeder 1)
4013: Registration sensor does not turn OFF (Paper feeder 2)
4014: Registration sensor does not turn OFF (Paper feeder 3)
4019: Registration sensor does not turn OFF (MP tray)
4020: Registration sensor is turned ON
4201: Eject sensor does not turn ON (Cassette)
4202: Eject sensor does not turn ON (Paper feeder 1)
4203: Eject sensor does not turn ON (Paper feeder 2)
4204: Eject sensor does not turn ON (Paper feeder 3)
4208: Eject sensor does not turn ON (Duplex)
4209: Eject sensor does not turn ON (MP tray)
4211: Eject sensor does not turn OFF (Cassette)
4212: Eject sensor does not turn OFF (Paper feeder 1)
4213: Eject sensor does not turn OFF (Paper feeder 2)
4214: Eject sensor does not turn OFF (Paper feeder 3)
4218: Eject sensor does not turn OFF (Duplex)
4219: Eject sensor does not turn OFF (MP tray)
4220: Eject sensor is turned ON
(b) Detail of paper source (Hexadecimal)
00: MP tray
01: Cassette 1
02: Cassette 2 (paper feeder 1)
03: Cassette 3 (paper feeder 2)
04: Cassette 4 (paper feeder 3)
05 to 09: Reserved
(c) Detail of paper size (Hexadecimal)
00: (Not specified)
01: Monarch
02: Business
03: International DL
04: International C5
05: Executive
06: Letter-R
86: Letter-E
07: Legal
08: A4R
88: A4E
09: B5R
89: B5E
0A: A3
0B: B4
0C: Ledger
0D: A5R
0E: A6
0F: B6
10: Commercial #9
11: Commercial #6
12: ISO B5
13: Custom size
1E: C4
1F: Postcard
20: Reply-paid post-
card
21: Oficio II
22: Special 1
23: Special 2
24: A3 wide
25: Ledger wide
26: Full bleed paper
(12 x 8)
27: 8K
28: 16K-R
A8: 16K-E
32: Statement-R
B2: Statement-E
33: Folio
34: Western type 2
35: Western type 4

Kyocera ECOSYS P6021cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	550 sheets
Total output capacity	- sheets
Maximum input capacity	1300 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound pressure level (printing)	48.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	61 W
Power consumption (printing)	353 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
