Kyocera ECOSYS P6021cdn Service Manual

2KT/2KV
1-4-3
Code Contents Conditions
Jam
location*
0100 Controller sequence error Secondary paper feed request given by the con-
troller is unreachable.
C
0105 Registration sensor not
detected
Activation of the registration sensor (on/off) is
undetected for 90 s during printing.
-
0106 Controller sequence error Paper feeding request for duplex printing given by
the controller is unreachable.
E
0110 Top tray open The top tray is opened during printing. -
0111 Rear cover open The rear cover is opened during printing. -
0112 Front cover open The waste toner cover is opened during printing. -
0113 MP tray open The MP tray is opened during printing. -
0120 Controller sequence error Paper feed request was received from the duplex
section despite the absence of paper in the duplex
section.
E
0121 Controller sequence error The controller issued the duplex section a request
for more pages than the duplex print cycle con-
tains.
E
0211 Rear cover open (paper
feeder 1)
The rear cover of paper feeder 1 is opened during
printing.
-
0212 Rear cover open (paper
feeder 2)
The rear cover of paper feeder 2 is opened during
printing.
-
0213 Rear cover open (paper
feeder 3)
The rear cover of paper feeder 3 is opened during
printing.
-
0501 No paper feed from cassette
1
The registration sensor (RS) does not turn on dur-
ing paper feed from cassette.
A
0502 No paper feed from cassette
2
PF feed sensor 1 (PFFS1) does not turn on during
paper feed from paper feeder 1.
F
0503 No paper feed from cassette
3
PF feed sensor 2 (PFFS2) does not turn on during
paper feed from paper feeder 2.
G
0504 No paper feed from cassette
4
PF feed sensor 3 (PFFS3) does not turn on during
paper feed from paper feeder 3.
H
0508 No paper feed from duplex
section
The registration sensor (RS) does not turn on dur-
ing paper feed from duplex section.
E
0509 No paper feed from MP tray MP feed sensor (MPFS) does not turn on during
paper feed from MP tray.
B
0511 Multiple sheets in cassette 1 The registration sensor (RS) does not turn off dur-
ing paper feed from cassette.
A
0512 Multiple sheets in cassette 2 PF feed sensor 1 (PFFS1) does not turn off during
paper feed from paper feeder 1.
F
0513 Multiple sheets in cassette 3 PF feed sensor 2 (PFFS2) does not turn off during
paper feed from paper feeder 2.
G
*: Refer to figure 1-4-2 for paper jam location (see page 1-4-2).

Kyocera ECOSYS P6021cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	550 sheets
Total output capacity	- sheets
Maximum input capacity	1300 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound pressure level (printing)	48.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	61 W
Power consumption (printing)	353 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
