2-2

Installing and Setting up the Machine > Part Names

Part Names

Machine Exterior

1Top Tray

2 Paper Stopper

3 Cassette 1

4 Power Switch

5 Handles

6 USB Memory Slot

7 Operation Panel

8 Handles

9 Rear Cover 1
