2-5

Installing and Setting up the Machine > Part Names

With Optional Equipments Attached

1 Cassette 2

2 Cassette 3

3 Cassette 4

4 Rear Cover 2

5 Rear Cover 3

6 Rear Cover 4

Optional Equipment (page 11-2)
