Kyocera FS-1120D Service Manual

2LY/2LZ-2
1-1-1
1-1-1 Specifications
Type................................................Desktop
Printing method...............................Electrophotography, laser scan
Paper weight...................................Cassette: 60 to 120 g/m
2
(Duplex: 60 to 105 g/m
2
)
MP tray: 60 to 220 g/m
2
Paper type ......................................Cassette:
Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color (Colour), Prepunched,
High quality, Custom 1 to 8
MP tray:
Plain, Transparency, Preprinted, Labels, Bond, Recycled, Rough, Vellum,
Letterhead, Color (Colour), Prepunched, Envelope, Cardstock, Thick paper,
High quality, Custom 1 to 8
Paper size ........................................Cassette:
A4, JIS B5, A5, Follio, Legal, Letter, Oficio II, Statement, Executive, A6, B6, ISO B5,
Envelope C5, 16K, Custom (105  148 to 216  356 mm/4 1/8  5 13/16 " to 8 1/2  14")
MP tray:
A4, JIS B5, A5, Follio, Legal, Letter, Oficio II, Statement, Executive, A6, B6, ISO B5,
Envelope C5, Envelope #10, Envelope #9, Envelope #6-
3/4 , Envelope Monarch,
Envelope DL, Hagaki, Ofuku Hagaki, 16K, Yokei 2, Yokei 4, Custom (70
 148 to 216 
356 mm/2 13/16  5 13/16 " to 8 1/2  14")
Printing speed.................................30/32 ppm model (A4/Letter)
Simplex printing Duplex printing
A4: 30 ppm A4: 17 ppm
Letter: 32 ppm Letter: 18 ppm
A5: 17 ppm
35/37 ppm model (A4/Letter)
Simplex printing Duplex printing
A4: 35 ppm A4: 19 ppm
Letter: 37 ppm Letter: 20 ppm
A5: 17 ppm
First print time.................................30/32 ppm model (A4/Letter)
6 s or less (A4, feed from cassette)
35/37 ppm model (A4/Letter)
7 s or less (A4, feed from cassette)
Warm-up time .................................Room temperature 22
°C/71.6°F, 60% RH
120 V AC model
Power on: 20 s or less
Sleep mode:15 s or less
220 - 240 V AC model
Power on: 19 s or less
Sleep mode:14 s or less
Paper capacity................................Cassette: 250 sheets (80 g/m
2
, Letter/A4 or smaller)
MP tray: 50 sheets (80 g/m
2
, Letter/A4 or smaller)
Output tray capacity........................Simplex printing: 250 sheets (80 g/m
2
)
Duplex printing: 200 sheets (80 g/m
2
)
Continuous printing.........................1 to 999 sheets
Photoconductor...............................OPC drum (diameter 30 mm)
Image write system.........................Semiconductor laser (1 beam)
Charging system.............................Scorotron (positive charging)
Developing system .........................Mono component dry developing method
Toner replenishing: Automatic from the toner container
Transfer system ..............................Transfer roller (negative-charged)
Separation system..........................Small diameter separation, discharger brush
Cleaning system .............................Drum: Counter blade
Charge erasing system...................Exposure by eraser lamp (LED)
Fusing system.................................Heat roller system
Resolution.......................................30/32 ppm model (A4/Letter)
Fast 1200 mode, 600 dpi, 300 dpi
35/37 ppm model (A4/Letter)
Fine 1200 mode, Fast 1200 mode, 600 dpi, 300 dpi

Kyocera FS-1120D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Memory type	DDR
Memory slots	1
Processor model	405F5
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.3 W
Power consumption (printing)	525 W
Power consumption (PowerSave)	4.4 W
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Printing colors	Black
Maximum duty cycle	20000 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
