FS-9120DN/9520DN
1-5-34
(17) Image is not
square.
Causes
1. Laser scanner unit positioned incorrectly.
Causes Check procedures/corrective measures
1. Laser scanner unit positioned incorrectly.
Adjust the installation position of the laser scanner unit
(see page 1-6-13).
(16) Image is out of fo-
cus.
Causes
1. Drum condensation.
Causes Check procedures/corrective measures
1. Drum condensation. Perform the drum refresh operation.
(15) Fusing is poor. Causes
1. Wrong type of paper.
2. Defective pressure springs.
3. Flawed press roller.
4. Defective fuser heater S.
Causes Check procedures/corrective measures
1. Wrong paper. Check if the paper meets specifications. Replace paper.
2. Defective pressure springs. Replace the pressure springs.
3. Flawed press roller. Replace the press roller (see page 1-6-19).
4. Defective fuser heater S. Replace the fuser heater S (see page 1-6-20).

Other manuals for Kyocera FS-9120DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-9120DN and is the answer not in the manual?

Kyocera FS-9120DN Specifications

General IconGeneral
I/O ports1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes88 x 148 mm - 297 x 450 mm
Power requirementsAC 220/240 V 50/60 Hz
Standard input trays2 x 500
Recommended media weight60 - 105 g/m²
Power consumption (active)920 W
Maximum print size297 x 420 mm
Maximum ISO A-series paper sizeA3
ColorNo
Print technologyLaser
Time to first page (black, normal)7 s
Print speed (black, normal quality, A4/US Letter)36 ppm
Memory slots2
Storage mediaHDD
Processor modelPower PC 750CX
Built-in processorYes
Maximum internal memory544 MB
Internal storage capacity20 GB
Sound power level (standby)39 dB
Sound pressure level (printing)53 dB
Total input capacity1200 sheets
Maximum input capacity4200 sheets
Paper tray 2 input capacity200 sheets
Maximum duty cycle55000 pages per month
Sustainability certificatesENERGY STAR
Power consumption (standby)160 W
Power consumption (PowerSave)12 W
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)585 x 639 x 615 mm
