Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-3-6
Terminals (YC) Voltage Remarks
1-1 1-7 0/5 V DC SLEEP signal, output
1-2 1-7 0/5 V DC CFM4 remote signal, output
1-3 1-7 0/5 V DC (pulse) Zero-cross signal, input
1-4 1-7 5 V DC 5 V DC supply for PSU, output
1-5 1-7 0/5 V DC FH-M on/off, output
1-6 1-7 0/5 V DC FH-S on/off, output
1-8 1-7 0 - 5 V DC Heater current monitor signal, input
2-1 2-2 24 V DC 24 V DC supply from SSW2, input
2-5 2-2 3.4 V DC 3.4 V DC supply from PSU, input
2-8 2-2 5 V DC 5 V DC supply from PSU, input
2-10 2-2 24 V DC 24 V DC supply from PSU, input
3-A1 3-A2 0/5 V DC (pulse) Serial signal for switchback unit*, input
3-A3 3-A4 0/5 V DC (pulse) Serial signal from switchback unit*, output
3-A5 3-A4 0/5 V DC Switchback unit* connection signal, input
3-A6 3-A4 0/5 V DC RESET signal for switchback unit*, output
3-B1 3-B2 0/5 V DC (pulse) Serial signal for paper feeder PF-70*/PF-75*, output
3-B3 3-B4 0/5 V DC (pulse) Serial signal from paper feeder PF-70*/PF-75*, input
3-B5 3-B4 0/5 V DC FSW on/off signal from paper feeder PF-70*/PF-75*, input
3-B6 3-B4 0/5 V DC RESET signal for paper feeder PF-70*/PF-75*, output
4-1 4-2 0/5 V DC (pulse) Serial signal from finisher*, input
4-3 4-4 0/5 V DC (pulse) Serial signal for finisher*, output
5-1 4-4 0/5 V DC RESET signal for finisher*, output
5-2 4-4 0/5 V DC Finisher* connection signal, input
6-A1 6-A4 0/5 V DC MPPWSW paper width detection signal, input
6-A2 6-A4 0/5 V DC MPPWSW paper width detection signal, input
6-A3 6-A4 0/5 V DC MPPWSW paper width detection signal, input
6-A5 6-A4 5 V DC 5 V DC supply for MPPSW, output
6-A6 6-A4 0/5 V DC MPPSW on/off, input
6-A8 6-A7 24 V DC 24 V DC supply for MPPFCL, output
6-A9 6-A7 0/24 V DC MPPFCL on/off, output
6-A10 6-A7 24 V DC 24 V DC supply for MPFCL, output
6-A11 6-A7 0/24 V DC MPFCL on/off, output
6-B1 6-B3 5 V DC 5 V DC supply for OFS, output
6-B2 6-B3 0/5 V DC OFS on/off, input
6-B4 6-B5 0/5 V DC WTDSW on/off, input
6-B6 6-B7 0/5 V DC FRCSW on/off, input
6-B8 6-B9 0/24 V DC CFM3 on/off, output
6-B10 6-B12 5 V DC 5 V DC supply for MPPLSW, output
6-B11 6-B12 0/5 V DC MPPLSW on/off, input
7-1 7-3 0 - 5 V DC Developing bias control voltage, output
7-2 7-3 24 V DC 24 V DC supply for HVTU, output
7-4 7-3 0/5 V DC Main charging on/off, output
7-5 7-3 0/5 V DC (pulse) Developing bias CLOCK signal, output
7-6 7-3 0/5 V DC Separation charging on/off, output
7-7 7-3 0 - 5 V DC Separation charging control voltage, output
7-8 7-3 0 - 5 V DC Transfer charging control voltage, output
7-9 7-3 0 - 5 V DC Transfer limit voltage, output
7-10 7-3 0/5 V DC Transfer charging on/off, output
7-11 7-3 0/5 V DC Transfer reverse bias remote signal, output
7-12 7-3 0/5 V DC Transfer forward bias remote signal, output
7-13 7-3 0/5 V DC Transfer current detection signal, input
7-14 7-3 0/5 V DC Transfer current detection signal, input
8-1 8-7 5 V DC 5 V DC supply for LSU, output
8-2 8-7 0/5 V DC LSU SAMPLE signal, output
8-3 8-7 0/5 V DC LSU POWCONT signal, output
8-4 8-7 0/5 V DC LSU LASER signal, output
*Optional.

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
