Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-3-7
Terminals (YC) Voltage Remarks
8-5 8-7 0/5 V DC LSU VIDEO + signal, output
8-6 8-7 0/5 V DC LSU VIDEO - signal, output
8-8 8-9 0/5 V DC LSU PD signal, input
8-10 8-11 24 V DC 24 V DC supply for PM, output
8-12 8-11 0/24 V DC PM SCAN signal, output
8-13 8-9 0/5 V DC PM READY signal, input
8-14 8-11 0/5 V DC (pulse) PM CLOCK signal, output
9-A2 9-A1 0/5 V DC MPFSW on/off, input
9-A3 9-A1 5 V DC 5 V DC supply for MPFSW, output
9-A4 9-A6 5 V DC 5 V DC supply for TCS, output
9-A5 9-A6 0/5 V DC TCS on/off, input
9-A8 9-A10 5 V DC 5 V DC supply for TNS, output
9-A9 9-A10 0/5 V DC TNS on/off, input
9-A11 9-A10 0/5 V DC Developing unit detection signal, input
9-A12 9-A10 0/5 V DC Developing unit FUSE CUT signal, output
9-B2 9-B1 0/24 V DC TNFSOL on/off, output
9-B3 9-B4 0/5 V DC TCDSW on/off, input
9-B7 9-B6 0/5 V DC CL on/off, output
9-B8 9-B6 0/5 V DC Drum unit DATA signal, output
9-B9 9-B6 0/5 V DC Drum unit CLOCK signal, output
9-B11 9-B10 0/5 V DC Drum unit detection signal, input
9-B12 9-B10 5 V DC 5 V DC supply for drum unit, output
10-A2 10-A1 0/5 V DC RSW on/off, input
10-A3 10-A1 5 V DC 5 V DC supply for RSW, output
10-A5 10-A8 5 V DC 5 V DC supply for FTH1, output
10-A6 10-A8 0 - 5 V DC FTH1 detection voltage, input
10-A7 10-A8 0/5 V DC FTH FUSE CUT signal, input
10-A9 10-A8 5 V DC 5 V DC supply for FTH2, output
10-A10 10-A8 0 - 5 V DC FTH2 detection voltage, input
10-B1 10-B3 24 V DC 24 V DC supply for DUPFCL, output
10-B2 10-B3 0/24 V DC DUPFCL on/off, output
10-B4 10-B3 0/5 V DC DUPPCSW on/off, input
10-B5 10-B3 5 V DC 5 V DC supply for DUPPCSW, output
10-B7 10-B6 0/5 V DC Duplex unit connection signal, input
10-B9 10-B3 5 V DC 24 V DC supply for CFM5, 6 ,7 , output
10-B10 10-B3 0/5 V DC CFM5, 6, 7 on/off, output
11-1 11-3 24 V DC 24 V DC supply for DM, output
11-2 11-4 24 V DC 24 V DC supply for PFM, output
11-5 11-7 5 V DC 5 V DC supply for DM, input
11-6 11-8 5 V DC 5 V DC supply for PFM, input
11-9 11-3 0/24 V DC DM S/S signal, output
11-10 11-4 0/24 V DC PFM S/S signal, output
11-11 11-3 0/24 V DC DM L/D signal, input
11-12 11-4 0/24 V DC PFM L/D signal, input
11-13 11-7 0/5 V DC (pulse) DM CLOCK signal, output
11-14 11-4 0/24 V DC FCL1 on/off, output
11-15 11-4 24 V DC 24 V DC supply for FCL1, output
11-17 11-16 0/5 V DC FSW1 on/off, input
11-18 11-16 5 V DC 5 V DC supply for FSW1, output
12-1 12-6 24 V DC 24 V DC supply for PWSW-U, output
12-2 12-6 24 V DC 24 V DC supply from PWSW-U, input
12-3 12-6 0/24 V DC PWSW-U paper width detection signal, input
12-4 12-6 0/24 V DC PWSW-U paper width detection signal, input
12-5 12-6 0/24 V DC PWSW-U paper width detection signal, input
12-7 12-12 24 V DC 24 V DC supply for PWSW-L, output
12-8 12-12 24 V DC 24 V DC supply from PWSW-L, input

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
