Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-3-8
Terminals (YC) Voltage Remarks
12-9 12-12 0/24 V DC PWSW-L paper width detection signal, input
12-10 12-12 0/24 V DC PWSW-L paper width detection signal, input
12-11 12-12 0/24 V DC PWSW-L paper width detection signal, input
13-A2 13-A1 0/5 V DC FSW3 on/off, input
13-A3 13-A1 5 V DC 5 V DC supply for FSW3, output
13-A4 13-A16 24 V DC 24 V DC supply for FCL3, output
13-A5 13-A16 0/24 V DC FCL3 on/off, output
13-A7 13-A6 0/5 V DC FSW2 on/off, input
13-A8 13-A6 5 V DC 5 V DC supply for FSW2, output
13-A10 13-A9 0/5 V DC SCSW on/off, input
13-A11 13-A16 24 V DC 24 V DC supply for FCL2, output
13-A12 13-A16 0/24 V DC FCL2 on/off, output
13-A13 13-A14 0/5 V DC LM-U paper level detection switch on/off, input
13-A15 13-A14 0/5 V DC LM-U paper level detection switch on/off, input
13-A17 13-A16 0/24 V DC LM-U on/off, output
13-A19 13-A18 0/5 V DC PLSW-L on/off, input
13-B2 13-B1 0/5 V DC PLSW-U on/off, input
13-B3 13-B4 0/5 V DC LM-L paper level detection switch on/off, input
13-B5 13-B4 0/5 V DC LM-L paper level detection switch on/off, input
13-B7 13-B6 0/24 V DC LM-L on/off, output
13-B9 13-B8 0/5 V DC LICSW-U on/off, input
13-B10 13-B8 5 V DC 5 V DC supply for LICSW-U, output
13-B12 13-B11 0/5 V DC PSW-U on/off, input
13-B13 13-B11 5 V DC 5 V DC supply for PSW-U, output
13-B15 13-B14 0/5 V DC LICSW-L on/off, input
13-B16 13-B14 5 V DC 5 V DC supply for LICSW-L, output
13-B18 13-B17 0/5 V DC PSW-L on/off, input
13-B19 13-B17 5 V DC 5 V DC supply for PSW-L, output
14-2 14-1 0/24 V DC CFM2 on/off, output
16-A1 16-A14 0/24 V DC FSSOL release signal, output
16-A2 16-A14 0/24 V DC FSSOL acutuate signal, output
16-A3 16-A14 24 V DC 24 V DC supply for FSSOL, output
16-A5 16-A4 0/5 V DC FSSW on/off, input
16-A6 16-A4 5 V DC 5 V DC supply for FSSW, input
16-A11 16-A10 0/5 V DC ESW on/off, input
16-A12 16-A10 5 V DC 5 V DC supply for ESW, output
16-A13 16-A14 0/24 V DC CFM1 on/off, output
16-A16 16-A15 0/5 V DC CCSW on/off, input
16-B1 16-A14 0/24 V DC PFCL-U on/off, output
16-B2 16-A14 24 V DC 24 V DC supply for PFCL-U, output
16-B3 16-A14 24 V DC 24 V DC supply for PFCL-L, output
16-B4 16-A14 0/24 V DC PFCL-L on/off, output
16-B5 16-A14 24 V DC 24 V DC supply for RCL, output
16-B6 16-A14 0/24 V DC RCL on/off, output
16-B7 16-B9 5 V DC 5 V DC supply for HUMSENS, output
16-B8 16-B9 0 - 5 V DC HUMSENS detection voltage, input
16-B10 16-B9 0 - 5 V DC ETTH detection voltage, input
16-B11 16-A14 0/24 V DC (pulse) EM coil energization pulse, output (B)
16-B12 16-A14 0/24 V DC (pulse) EM coil energization pulse, output (B)
16-B13 16-A14 0/24 V DC (pulse) EM coil energization pulse, output (A)
16-B14 16-A14 0/24 V DC (pulse) EM coil energization pulse, output (A)
16-B15 16-A14 24 V DC 24 V DC supply for CFM4, output
16-B16 16-A14 0/24 V DC CFM4 on/off, output
21-1 21-2 0/5 V DC OPPWB FPRSTN signal, output
21-3 21-2 0/5 V DC OPPWB FPCLK signal, input
21-4 21-2 0/5 V DC OPPWB FPDIR signal, input

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
