Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-3-9
Terminals (YC) Voltage Remarks
21-5 21-2 0 - 5 V DC OPPWB FPDAT signal, input
21-6 21-2 5 V DC 5 V DC supply for OPPWB, output
22-A1 22-A2 5/0 V DC (pulse) Main controller PWB PRINTN signal, output
22-A3 22-A2 5/0 V DC (pulse) Main controller PWB SI signal, output
22-A4 22-A2 5/0 V DC (pulse) Main controller PWB SCLK signal, input
22-A5 22-A2 5/0 V DC (pulse) Main controller PWB SBSY signal, output
22-A6 22-A2 5/0 V DC (pulse) Main controller PWB SO signal, input
22-A7 22-A2 5/0 V DC (pulse) Main controller PWB RESET signal, output
22-A8 22-A2 5/0 V DC (pulse) Main controller PWB PDOUT signal, output
22-A10 22-A2 5/0 V DC (pulse) Main controller PWB VDATAP signal, input
22-A12 22-A2 5/0 V DC (pulse) Main controller PWB VDATAN signal, input
22-A14 22-A2 5/0 V DC (pulse) Main controller PWB FPCLK signal, output
22-A15 22-A2 5/0 V DC (pulse) Main controller PWB FPDAT signal, input
22-A17 22-A2 5/0 V DC (pulse) Main controller PWB VDATA signal, input
22-B1 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B2 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B3 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B4 22-A2 5/0 V DC (pulse) Main controller PWB SDIR signal, output
22-B5 22-A2 5/0 V DC (pulse) Main controller PWB ESGIR signal, output
22-B6 22-A2 5/0 V DC (pulse) Main controller PWB VDFON signal, output
22-B7 22-A2 5/0 V DC (pulse) Main controller PWB VSREQN signal, output
22-B12 22-A2 5/0 V DC (pulse) Main controller PWB FPDIR signal, output
22-B13 22-A2 5/0 V DC (pulse) Main controller PWB FPPOWER signal, output
22-B15 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B16 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B17 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B18 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B19 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B20 22-A2 5 V DC Main controller PWB 5 V DC supply, output

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
