Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-4-2
Timing chart No. 2 One sheet printing from the MP tray
YC11-9,11
YC11-10,12
YC16-B6
YC6-A9
YC6-A11
YC7-4
YC16-B11 - B14
YC10-A2
YC16-A11
YC9-A2
YC7-10
YC7-1
YC7-6
YC11-14
Print start signal
DM
PFM
RCL
MPPFCL
MPFCL
MC REM
EM
RSW
ESW
MPFSW
TC REM
DB REM
SC REM
FCL1
100 ms
300 ms
280 ms
100 ms
35 ms
325/260 ms*
260/202 ms*
309/239 ms*
*: FS-9120DN/9520DN
154 - 255 ms
84 ms
124/96 ms*
100 ms
5000 ms
41 ms
375/300 ms*
Image ready

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
