Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-4-1
Timing chart No. 1 From the power switch turned on to machine stabilization
POWSW: On
POWSW
FH-M
FH-S
DM
DB REM
YC1-1
YC1-5
YC1-6
YC11-9,11
YC7-1
CFM (second speed)
CFM (first speed)
PM
TC REM
YC8-12
YC7-10
300 ms
10 s
*2
100 ms
300 ms
+400 V +3000 V +400 V
8 s
1 s
500 ms
1 s
1000 ms
*1: Printing is enabled as follows:
1. When fixing temperature at the power switch turning on is 100
°C/212°F or lower
Absolute humidity is 15 g/m
3
or higher:
Printing is enabled 120 s after fuser heater M (FH-M) turning on.
2. When fuser temperature at the power switch turning on is 100
°C/212°F or lower
The fuser temperature at the power switch turning on is 13
°C/55.4°F or higher and the ambient temperature is 18
°C/64.4°F or higher:
Printing is enabled at the earlier timing of either 41 s after fuser heater M (FH-M) turning on or when the printer enters se
condary stabilization.
Other than the above:
Printing is enabled at the later timing of either 69 s after fuser heater M (FH-M) turning on or when the printer enters seco
ndary stabilization.
3. Other conditions than 1 and 2
Printing is enabled when the printer enters secondary stabilization.
*2: 60 s when the fuser temperature at power switch turning on is 100
°C/212°F or lower, and the absolute humidity is 15 g/m
3
or higher.
Primary stabilization
fuser temperature
115°C/239°F (FS-9120DN)
120°C/248°F (FS-9520DN)
or time out 13 s
Secondary stabilization
fuser temperature
130°C/266°F (FS-9120DN)
145°C/293°F (FS-9520DN)
or time out 13 s
Printing enabled
*1
Half speed
30 s
540 ms

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
