Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-3-13
Terminals (YC) Voltage Remarks
3-9 3-16 0/5 V DC (pulse) Parallel I/F DATA8 signal
3-10 3-16 0/5 V DC (pulse) Parallel I/F ACK signal
3-11 3-16 0/5 V DC (pulse) Parallel I/F BUSY signal
3-12 3-16 0/5 V DC (pulse) Parallel I/F PE signal
3-13 3-16 0/5 V DC (pulse) Parallel I/F SEL signal
3-14 3-16 0/5 V DC (pulse) Parallel I/F CAN signal
3-15 3-16 0/5 V DC (pulse) Parallel I/F RMR signal
3-18 3-16 0/5 V DC (pulse) Parallel I/F INIT signal
3-30 3-16 0/5 V DC (pulse) Parallel I/F ARARM signal
3-31 3-16 0/5 V DC (pulse) Parallel I/F ASFON signal
3-32 3-16 0/5 V DC (pulse) Parallel I/F FAULT signal
3-33 3-16 0/5 V DC (pulse) Parallel I/F HSTI signal
3-34 3-16 0/5 V DC (pulse) Parallel I/F EXPRM signal
3-35 3-16 0/5 V DC (pulse) Parallel I/F PRDY signal
3-36 3-16 0/5 V DC (pulse) Parallel I/F SELI signal
4-1 4-4 0/5 V DC (pulse) USB VBUS signal
4-2 4-4 0/5 V DC (pulse) USB DATA+ signal
4-3 4-4 0/5 V DC (pulse) USB DATA- signal
6-A1 6-A2 5/0 V DC (pulse) Engine controller PWB PRINTN signal
6-A3 6-A2 5/0 V DC (pulse) Engine controller PWB SI signal
6-A4 6-A2 5/0 V DC (pulse) Engine controller PWB SCLK signal
6-A5 6-A2 5/0 V DC (pulse) Engine controller PWB SBSY signal
6-A6 6-A2 5/0 V DC (pulse) Engine controller PWB SO signal
6-A7 6-A2 5/0 V DC (pulse) Engine controller PWB RESET signal
6-A8 6-A2 5/0 V DC (pulse) Engine controller PWB PDOUT signal
6-A10 6-A2 5/0 V DC (pulse) Engine controller PWB VDATAP signal
6-A12 6-A2 5/0 V DC (pulse) Engine controller PWB VDATAN signal
6-A14 6-A2 5/0 V DC (pulse) Engine controller PWB FPCLK signal
6-A15 6-A2 5/0 V DC (pulse) Engine controller PWB FPDAT signal
6-A17 6-A2 5/0 V DC (pulse) Engine controller PWB VDATA signal
6-B1 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B2 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B3 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B4 6-A2 5/0 V DC (pulse) Engine controller PWB SDIR signal
6-B5 6-A2 5/0 V DC (pulse) Engine controller PWB ESGIR signal
6-B6 6-A2 5/0 V DC (pulse) Engine controller PWB VDFON signal
6-B7 6-A2 5/0 V DC (pulse) Engine controller PWB VSREQN signal
6-B12 6-A2 5/0 V DC (pulse) Engine controller PWB FPDIR signal
6-B13 6-A2 5/0 V DC (pulse) Engine controller PWB FPPOWER signal
6-B15 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B16 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B17 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B18 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B19 6-A2 5 V DC Engine controller PWB 5 V DC supply, input
6-B20 6-A2 5 V DC Engine controller PWB 5 V DC supply, input

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
