Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-3-12
Terminals (YC) Voltage Remarks
2-2 2-1 0/5 V DC (pulse) Compact flash D3 signal
2-3 2-1 0/5 V DC (pulse) Compact flash D4 signal
2-4 2-1 0/5 V DC (pulse) Compact flash D5 signal
2-5 2-1 0/5 V DC (pulse) Compact flash D6 signal
2-6 2-1 0/5 V DC (pulse) Compact flash D7 signal
2-7 2-1 0/5 V DC (pulse) Compact flash _CE1 signal
2-8 2-1 0/5 V DC (pulse) Compact flash A10 signal
2-9 2-1 0/5 V DC (pulse) Compact flash _OE signal
2-10 2-1 0/5 V DC (pulse) Compact flash A9 signal
2-11 2-1 0/5 V DC (pulse) Compact flash A8 signal
2-12 2-1 0/5 V DC (pulse) Compact flash A7 signal
2-13 2-1 0/5 V DC (pulse) Compact flash VCC signal
2-14 2-1 0/5 V DC (pulse) Compact flash A6 signal
2-15 2-1 0/5 V DC (pulse) Compact flash A5 signal
2-16 2-1 0/5 V DC (pulse) Compact flash A4 signal
2-17 2-1 0/5 V DC (pulse) Compact flash A3 signal
2-18 2-1 0/5 V DC (pulse) Compact flash A2 signal
2-19 2-1 0/5 V DC (pulse) Compact flash A1 signal
2-20 2-1 0/5 V DC (pulse) Compact flash A0 signal
2-21 2-1 0/5 V DC (pulse) Compact flash D0 signal
2-22 2-1 0/5 V DC (pulse) Compact flash D1 signal
2-23 2-1 0/5 V DC (pulse) Compact flash D2 signal
2-24 2-1 0/5 V DC (pulse) Compact flash WP signal
2-25 2-1 0/5 V DC (pulse) Compact flash _CD2 signal
2-26 2-1 0/5 V DC (pulse) Compact flash _CD1 signal
2-27 2-1 0/5 V DC (pulse) Compact flash D11 signal
2-28 2-1 0/5 V DC (pulse) Compact flash D12 signal
2-29 2-1 0/5 V DC (pulse) Compact flash D13 signal
2-30 2-1 0/5 V DC (pulse) Compact flash D14 signal
2-31 2-1 0/5 V DC (pulse) Compact flash D15 signal
2-32 2-1 0/5 V DC (pulse) Compact flash _CE2 signal
2-33 2-1 0/5 V DC (pulse) Compact flash _VS1 signal
2-34 2-1 0/5 V DC (pulse) Compact flash _IORD signal
2-35 2-1 0/5 V DC (pulse) Compact flash _IOWR signal
2-36 2-1 0/5 V DC (pulse) Compact flash _WE signal
2-37 2-1 0/5 V DC (pulse) Compact flash RDY/_BSY signal
2-38 2-1 0/5 V DC (pulse) Compact flash VCC signal
2-39 2-1 0/5 V DC (pulse) Compact flash _CSEL signal
2-40 2-1 0/5 V DC (pulse) Compact flash _VS2 signal
2-41 2-1 0/5 V DC (pulse) Compact flash RESET signal
2-42 2-1 0/5 V DC (pulse) Compact flash _WAIT signal
2-43 2-1 0/5 V DC (pulse) Compact flash _INPACK signal
2-44 2-1 0/5 V DC (pulse) Compact flash _REG signal
2-45 2-1 0/5 V DC (pulse) Compact flash BVD2 signal
2-46 2-1 0/5 V DC (pulse) Compact flash BVD1 signal
2-47 2-1 0/5 V DC (pulse) Compact flash D8 signal
2-48 2-1 0/5 V DC (pulse) Compact flash D9 signal
2-49 2-1 0/5 V DC (pulse) Compact flash D10 signal
3-1 3-16 0/5 V DC (pulse) Parallel I/F STB signal
3-2 3-16 0/5 V DC (pulse) Parallel I/F DATA1 signal
3-3 3-16 0/5 V DC (pulse) Parallel I/F DATA2 signal
3-4 3-16 0/5 V DC (pulse) Parallel I/F DATA3 signal
3-5 3-16 0/5 V DC (pulse) Parallel I/F DATA4 signal
3-6 3-16 0/5 V DC (pulse) Parallel I/F DATA5 signal
3-7 3-16 0/5 V DC (pulse) Parallel I/F DATA6 signal
3-8 3-16 0/5 V DC (pulse) Parallel I/F DATA7 signal

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
