1-3-14
FS-9120DN/9520DN
1-3-6 Installing the memory card (option)
Procedure
1. Turn off the printer.
Note: Do not insert or remove a memory card
(CompactFlash) while power in on. If the
memory card is removed while the
printer is on, damage could result in the
printer's electronics or the memory card.
2. Insert the memory card in the slot. Insert it as
its label surface facing toward outside,
connector end first. Push it in all the way.
Figure 1-3-31
CF card
