Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
1-5-29
Causes Check procedures/corrective measures
1. No main charging.
A. Broken main charger wire.
B. Leaking main charger housing.
C. The connector terminals of the high-voltage
transformer PWB make poor contact.
D. Defective engine controller PWB.
E. Defective high-voltage transformer PWB.
2. Video data problem.
A. Defective main controller PWB.
(1) No image appears
(entirely white).
Causes
1. No transfer charging.
2. No laser beam output.
3. No developing bias is output.
Causes Check procedures/corrective measures
1. No transfer charging.
A. The connector terminals of the high-voltage
transformer PWB make poor contact.
B. Defective engine controller PWB.
C. Defective high-voltage transformer PWB.
2. No laser beam output.
A. Defective laser scanner unit.
B. Defective engine controller PWB.
3. No developing bias is output.
A. Defective engine controller PWB.
B. Defective high-voltage transformer PWB.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
Replace the engine controller PWB (see page 1-6-24).
Replace the high-voltage transformer unit (see page 1-6-26).
Replace the laser scanner unit (see page 1-6-11).
Replace the engine controller PWB (see page 1-6-24).
Replace the engine controller PWB (see page 1-6-24).
Replace the high-voltage transformer unit (see page 1-6-26).
(2) No image appears
(entirely black).
Replace the main charger unit.
Clean the main charger wire, grid and shield.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
Replace the engine controller PWB (see page 1-6-24).
Replace the high-voltage transformer unit (see page 1-6-26).
Replace the main controller PWB (see page 1-6-23).
Causes
1. No main charging.
2. Video data problem.

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
