Kyocera FS-C5015N User Manual

Introduction
iv ADVANCED OPERATION GUIDE
Conventions
This manual uses the following conventions:
Convention Description Example
Italic Typeface Used to emphasize a key word,
phrase or message. In addition,
references to other publications
are displayed in italic typeface.
Close the top cover.
Refer to Toner Container Replacement
on page 3-3.
Bracket Bold Text
Typeface
Used to emphasise the
selection of a feature mode or
key.
Press [Copy].
Notes Used to provide additional or
useful information about a
function or feature. Can also
contain references to other
publications.
NOTE: For information about storing the
pin, refer to step 10.
Important Use to provide important
information.
IMPORTANT: Ensure paper is not
folded, curled, or damaged.
Caution Cautions are statements that
suggest mechanical damage as
a result of an action.
CAUTION: Do not pull the cassette out
when holding the front of the machine.
Warning Used to alert users to the
possibility of personal injury.
WARNING: High voltage is present
in the charger section.

Kyocera FS-C5015N Specifications

General

I/O ports	USB 2.0
Power requirements	AC 220 ~ 240 V, 50/60 Hz
Standard media sizes	A 4, B 5, A 5, Letter, Legal, Custom (148 x 210 mm – 216 x 356 mm)
Power consumption (active)	452 W
Internal memory	128 MB
Processor model	PowerPC 750CXr
Built-in processor	Yes
Sound power level (standby)	36 dB
Sound pressure level (printing)	52 dB
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (color, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1000 sheets
Maximum duty cycle	50000 pages per month
Power consumption (standby)	173 W
Power consumption (PowerSave)	16 W
Certification	TÜV/GS, CE This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard.

Weight and Dimensions

Dimensions (WxDxH)	345 x 470 x 385 mm
