Kyocera FS-C5015N User Manual

Using the Operator Panel
2-64 ADVANCED OPERATION GUIDE
A4
Executive
Letter
Legal
7
When the desired paper size is displayed, press [OK] ([ENTER]). The
paper size is set for the paper cassette.
If you selected Custom in step 6, be sure to set the unit of measurement
and the dimensions of the paper as described in the following sections.
8
Select the units of measurement as described in the next section.
Selecting the Unit of Measurement
1
Press Z.
2
Press U or V repeatedly until >>Unit
appears. The unit of measurement can be
selected between millimeters and inches.
The current unit of measurement is
displayed (the default setting is mm).
3
Press [OK] ([ENTER]). A blinking question
mark (?) appears.
4
Select mm or inch using U or V.
5
Press [OK] ([ENTER]).
Set the dimensions of the paper as described in the next section.
Entering the Width and Length
1
Enter the paper size for X Dimension and Y Dimension as shown in the
figure.
>>Unit
mm
>>Unit
? mm
X Dimension
Y Dimension
148 to 216mm
(5.83 to 8.5 inches)
210 to 356mm
(8.27 to 14.02 inches)

Kyocera FS-C5015N Specifications

General

I/O ports	USB 2.0
Power requirements	AC 220 ~ 240 V, 50/60 Hz
Standard media sizes	A 4, B 5, A 5, Letter, Legal, Custom (148 x 210 mm – 216 x 356 mm)
Power consumption (active)	452 W
Internal memory	128 MB
Processor model	PowerPC 750CXr
Built-in processor	Yes
Sound power level (standby)	36 dB
Sound pressure level (printing)	52 dB
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (color, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1000 sheets
Maximum duty cycle	50000 pages per month
Power consumption (standby)	173 W
Power consumption (PowerSave)	16 W
Certification	TÜV/GS, CE This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard.

Weight and Dimensions

Dimensions (WxDxH)	345 x 470 x 385 mm
