2HL/2HM/2HN
1-5-31
10. Remove the lever link.
Figure 1-5-41
11. Remove the twenty connectors.
Figure 1-5-42
Lever link
YC39
YC3
YC28
YC15
YC26
YW
YC33
YC40
YC17
BK
YC44
YC25
YC22
YC23
YC38
YC37 YC36
YC34
YC11YC24
YC18
YC27
RD
BK YW
GY
BE
BE
Connectors
