2HL/2HM/2HN
2-3-10
YC41 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the devel-
oping fan
motor 2
2 DLPFANDRN O 0/12/24 V DC Developing fan motor 2: Full speed/Half speed/Off
YC43 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the ID
solenoid
2 IDSOLDRN O 0/24 V DC ID solenoid: On/Off
YC44 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the fuser
fan motor 2
2 SUBFANDRN O 0/12/24 V DC Fuser fan motor 2: Full speed/Half speed/Off
Connector Pin Signal I/O Voltage Description
