Kyocera FS-C5300DN Service Manual

2HL/2HM/2HN
1-4-21
1-4-3 Image formation problems
(1)No image appears
(entirely white).
(2)No image appears
(entirely black).
(3)A specific color is
printed solid.
(4)The back side gets
dirty.
(5)Image is too light.
See page 1-4-22 See page 1-4-22 See page 1-4-23 See page 1-4-23 See page 1-4-23
(6)The background is
colored.
(7)White streaks are
printed vertically.
(8)Black streaks are
printed vertically.
(9)Streaks are printed
horizontally.
(10)Spots are printed.
See page 1-4-24 See page 1-4-24 See page 1-4-24 See page 1-4-25 See page 1-4-25
(11)The leading edge
of image begins to
print too early or too
late.
(12)Paper is wrinkled. (13)Offset occurs. (14)Part of image is
missing.
(15)Fusing is loose.
See page 1-4-25 See page 1-4-25 See page 1-4-26 See page 1-4-26 See page 1-4-26
(16)Colors are printed
offset to each other.
See page 1-4-26
