Kyocera FS-C5300DN Service Manual

2HL/2HM/2HN
2-4-3
(2) Repetitive defects gauge
31 mm ( ") Rear registration roller
First occurrence of defect
50 mm ( ") Front registration roller
50 mm
( ") Developing roller
59 mm
( ") Transfer roller
79 mm
( ") Press roller
82 mm
( ") Heat roller*
1
98 mm (3 11/16"??????????????) Drum
98 mm
(3 11/16"??????????????) Heat roller*
2
*
2
: 21/23 ppm (250-sheet) model
*
1
: 26/28 ppm (500-sheet) model
21/23 ppm (500-sheet) model
