Using the Operation Panel 2-27
3 Press V repeatedly until Delete appears below the title.
4 Press [OK]. The message Processing appears and the stored job
is deleted.
Private/Stored (Printing a private print/stored job)
In private printing, you can specify that a job is not printed until you
release the job from the operation panel. When sending the job from the
application software, specify a 4-digit access code in the printer driver.
The job is released for printing by entering the access code on the
operation panel ensuring confidentiality of the print job.
In the stored job mode, access codes are not mandatory, but can be set
on the printer driver if printing with PIN security is required. Then, the
access code must be entered on the operation panel to print a stored job.
Print data will be stored in the hard disk/RAM disk after printing.
Refer to KX Printer Driver User Guide for the driver settings.
Releasing a Private/Stored Job
1 Press Z while Job Box > is displayed.
2 Press U or V repeatedly until >Private/Stored appears. The
name entered in the printer driver (Harold, in this example) also
appears.
3 Press [OK]. A blinking question mark (?) appears before the user
name.
4 Press U or V to display the desired user name (Arlen, in this
example).
5 Press [OK]. The user name and the job name (Agenda, in this
example) entered in the printer driver appear with a blinking question
mark (?).
6 Press U or V to display the desired job title.
7 Press [OK]. The ID input line appears. Enter the four-digit access
code entered in the printer driver and press [OK].
To enter the ID, press Y or Z to move the cursor to the number to be
changed and then enter the correct number by pressing U or V.
IMPORTANT If you selected All Files and the stored access
code does not match any of the documents, or if no access codes
was specified,
ID error is displayed.
8 You can set the number of copies to be printed. To increase the copy
count, press U; to decrease the copy count, press V.
Note If you selected All Files, this process is applied to all
the documents in the Private/Stored Job.
Note If you selected All Files, press U after Copies --- is
displayed to set the number of copies.
>Report
Delete
>Private/Stored
?Harold
>Arlen
?Agenda
>Agenda
ID 0000
>Agenda
Copies 001

Table of Contents

Other manuals for Kyocera FS-C5350DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-C5350DN and is the answer not in the manual?

Kyocera FS-C5350DN Specifications

General IconGeneral
ColorYes
Maximum resolution9600 x 600 DPI
Time to first page (black, normal)8.5 s
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Internal memory256 MB
Processor modelPowerPC 750CL
Maximum internal memory1280 MB
Sound power level (standby)36 dB
Sound pressure level (printing)55 dB
Total input capacity150 sheets
Total output capacity250 sheets
Maximum input capacity2150 sheets
Maximum print size210 x 297 mm
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
SafetyGS, TÜV, CE
Power managementAC 220 - 240 V, 50/60 Hz
Custom media sizes70 x 138 mm - 216 x 356 mm
Networking features10/100BaseTX
Power consumption (active)516 W
Compatible operating systemsWindows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle100000 pages per month
Power consumption (standby)74 W
Power consumption (PowerSave)8 W
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)345 x 518 x 480 mm
