2-28 Using the Operation Panel
9 Press [OK] to finalize the copy count. The printer prints the specified
number of copies for the job.
Deleting a Private/Stored Job
You can individually delete stored jobs by performing the following
procedure. Jobs saved using Private Print will be automatically deleted if
you turn the power off after printing, but jobs saved using Stored Job will
not be deleted automatically.
1 Follow steps 1 through 6 in the above section.
2 When the title of the job to be printed is displayed (Agenda, in this
example), press [OK]. Enter the four-digit access code entered in the
printer driver and press [OK].
3 Press V repeatedly until Delete appears for the number of copies.
4 Press [OK]. The private job is deleted.
Job Box Configuration
Change Job Box settings, such as the maximum number of storable
documents in the hard disk, and automatic delete settings.
The following items are available in the Job Box detail settings.
Changing the Maximum Number of Quick Copy
Set Automatic Delete times for Temporary Jobs
Changing the Maximum Number of Quick Copy
This changes maximum number of Quick Copy from 0 to 50. The default
is 32.
1 Press Z while Job Box > is displayed.
2 Press U or V repeatedly until >Job Box Configuration >
appears.
3 Press Z.
4 Press U or V repeatedly until >>Quick Copy appears.
5 Press [OK]. A blinking cursor (_) appears.
6 Press U or V to increase or decrease the value at the blinking cursor.
The value can be set between 0 and 50. Use Y and Z to move the
cursor right and left.
7 When the desired maximum number of jobs is set, press [OK].

Table of Contents

Other manuals for Kyocera FS-C5350DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-C5350DN and is the answer not in the manual?

Kyocera FS-C5350DN Specifications

General IconGeneral
ColorYes
Maximum resolution9600 x 600 DPI
Time to first page (black, normal)8.5 s
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Internal memory256 MB
Processor modelPowerPC 750CL
Maximum internal memory1280 MB
Sound power level (standby)36 dB
Sound pressure level (printing)55 dB
Total input capacity150 sheets
Total output capacity250 sheets
Maximum input capacity2150 sheets
Maximum print size210 x 297 mm
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
SafetyGS, TÜV, CE
Power managementAC 220 - 240 V, 50/60 Hz
Custom media sizes70 x 138 mm - 216 x 356 mm
Networking features10/100BaseTX
Power consumption (active)516 W
Compatible operating systemsWindows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle100000 pages per month
Power consumption (standby)74 W
Power consumption (PowerSave)8 W
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)345 x 518 x 480 mm
