Kyocera TASKalfa 4551ci Service Manual

2L6/2N6/2N5/2N4
1-4-198
F040 Communication error
between Main PWB and
Print engine
Main PWB
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Repair or replace the wire from the
engine PWB, that may be grounded.
(Check short-circuit between 5V and
3.3V.)
3. Check that the FFC wire connecting
between the main PWB (YC3) and the
engine PWB (YC46) is normal and, if
necessary, re-insert.Or, replace the FFC
wire.
4. If not corrected, replace the main PWB
(see page 1-5-72).
Engine PWB
1. Check the engine software and upgrade
to the latest, if necessary.
2. Replace the engine PWB (see page 1-5-
80).
HDD Replace the HDD (see page 1-5-119).
F041 Communication error
between Main PWB and
Scanner engine
Main PWB
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Check that the wires between the main
PWB and the ISC PWB are normal.
3. If not corrected, replace the main PWB
(see page 1-5-72).
ISC PWB Replace the ISC PWB.
F050 Print engine ROM check-
sum error
Engine software Install the latest engine software.
Engine PWB
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Confirm that the EEPROM has been
properly installed.
3. If not corrected, Replace the engine
PWB (see page 1-5-80).
F051 Scanner engine ROM
checksum error
Scanner software Install the latest scanner software.
ISC PWB
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Confirm that the EEPROM has been
properly installed.
3. If not corrected, Replace the ISC PWB.
F278 Power supply in drive sys-
tem error
The main power
switch was turned
off before the
power switch is
pressed. Shutdown
due to a power
failure
Turn the main power swtch off and after 5
seconds, then turn power on.
(Before turning power off, verify that the
power key has been pressed and the power
indicator has gone off, then switch the main
power switch.)
Code Contents Related parts
Check procedures/
corrective measures

Kyocera TASKalfa 4551ci Specifications

General

Duplex printing	Yes
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	3.9 s
Time to first page (color, normal)	5.1 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, USB
Maximum scan area	A3 (297 x 420) mm
Scan speed (color)	160 ppm
Image formats supported	JPG, TIF
Faxing	Color faxing
Fax memory	12 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL
Paper input type	Cassette, Paper tray
Total input capacity	1150 sheets
Total output capacity	250 sheets
Maximum input capacity	7650 sheets
Total number of input trays	3
Multi-Purpose tray input capacity	150 sheets
Maximum print size	297 x 420 mm
Duplex media weight	60 - 256 g/m²
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 300 g/m²
Display	LCD
Product color	Gray
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Processor model	P1022
Processor family	PMC-Sierra
Internal storage capacity	320 GB
Sound power level (standby)	38.3 dB
Sound pressure level (printing)	50.9 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	1.8 W
Power consumption (average operating)	1030 W
Sustainability certificates	RoHS

Weight and Dimensions

Depth	767 mm
Width	668 mm
Height	747 mm
