Kyocera TASKalfa 4551ci Service Manual

2L6/2N6/2N5/2N4
1-4-72
1030 PF lift motor 1 error
(paper feeder)
After cassette 3 is inserted,
PF lift sensor 1 does not turn
on within 12 s. This error is
detected 5 times successively.
During driving the motor, the
lift overcurrent protective
monitor signal is detected for
1 s or more 5 times succes-
sively. However, the first 1 s
after motor is turned on is
excluded from detection.
Cassette lift base
elevating
mechanism
Check that the cassette base can be
manipulated smoothly, if not, repair or
replace.
PF Lift motor 1 1. Check that the cassette base has been
ascended.
2. Check the drive gear can rotate or they
are not unusually loaded and, if
necessary, replace.
3. Confirm that the wiring connector is
firmly connected and, if necessary,
connect the connector all the way in.
PF Lift motor 1 and main PWB (YC7)
4. If the wiring is disconnected, shorted or
grounded, replace the wiring.
5. PFReplace the lift motor 1.
PF Lift sensor 1 1. Check that the sensor is correctly
positioned.
2. Confirm that the wiring connector is
firmly connected and, if necessary,
connect the connector all the way in.
PF Lift sensor 1 and PF main PWB
(YC7)
3. If the wiring is disconnected, shorted or
grounded, replace the wiring.
4. Replace the lift sensor 1.
PF main PWB
Replace the PF main PWB (Refer to the
service manual for the paper feeder).
Code Contents Related parts
Check procedures/
corrective measures

Kyocera TASKalfa 4551ci Specifications

General

Duplex printing	Yes
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	3.9 s
Time to first page (color, normal)	5.1 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, USB
Maximum scan area	A3 (297 x 420) mm
Scan speed (color)	160 ppm
Image formats supported	JPG, TIF
Faxing	Color faxing
Fax memory	12 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL
Paper input type	Cassette, Paper tray
Total input capacity	1150 sheets
Total output capacity	250 sheets
Maximum input capacity	7650 sheets
Total number of input trays	3
Multi-Purpose tray input capacity	150 sheets
Maximum print size	297 x 420 mm
Duplex media weight	60 - 256 g/m²
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 300 g/m²
Display	LCD
Product color	Gray
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Processor model	P1022
Processor family	PMC-Sierra
Internal storage capacity	320 GB
Sound power level (standby)	38.3 dB
Sound pressure level (printing)	50.9 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	1.8 W
Power consumption (average operating)	1030 W
Sustainability certificates	RoHS

Weight and Dimensions

Depth	767 mm
Width	668 mm
Height	747 mm
