Digital OverVoltage Relay (GDR-C01) User's Manual V1.00
14 / 47
Kyongbo Electronics Co., Ltd.
2.8 Mechanical Test
Vibration
Vibration
Response Test
10 ~ 150Hz, 0.5G, Front/Back, Left/Right,
Up/Down
1 time
Vibration
Endurance Test
10 ~ 150Hz, 1G, Front/Back, Left/Right, Up/Down
20 times
Shock
Shock Response
Test
5G, Front/Back, Left/Right, Up/Down
3 times
Shock Withstand
Test
15G, Front/Back, Left/Right, Up/Down
3 times
Bump Test
10G, Front/Back, Left/Right, Up/Down
1000 times
Earthquake
1 ~ 8㎐
x : 3.5mm, y : 1.5mm, Sweep : 1 time
8 ~ 35㎐
x : 1g, y : 0.5g, Sweep : 1 time
【Table 2.7】 Vibration, Shock, Earthquake
2.9 Noise Test
1MHz burst disturbance
1MHz, 75ns,
400Hz, 2Sec
Common
mode
2.5kV
IEC60255-22-1
Differential
mode
1.0kV
EFT Burst
Applied Voltage
4kV
IEC60255-22-4
Repeated
Frequency
2.5kHz
Electrostatic Discharge
Air discharge
8kV
IEC60255-22-2
Contact discharge
6kV
Surge Electrical
Disturbance
1.2/50μs, 8/20μs,
30sec, 3 times
Common
mode
2.0kV
IEC60255-22-5
Differential
mode
1.0kV
Radio Frequency
Radiation Endurance
80MHz ~ 1GHz, 10V/m, 1sec
IEC60255-22-3
Radio Frequency
Conduction Endurance
150kHz ~ 80MHz, 10V/m, 1sec
IEC60255-22-6
【Table 2.8】 Noise Endurance
