KYORITSU 4116A - Servicing; Case and Strap Belt Assembly

― 17 ―
7.SERVICING
Ifthistestershouldfailtooperatecorrectly,returnittoyourdistributorstating
theexactnatureofthefault.
Pleaseremembertogivealltheinformationpossibleconcerningthenature
ofthefault,asthiswillmeanthattheinstrumentwillbe servicedand
returnedtoyoumorequickly.
8.CASEANDSTRAPBELTASSEMBLY
CorrectassemblyisshowninFig12.Byhangingtheinstrumentroundthe
neck,bothhandswillbeleftfreefortesting.
WARNING
● Thisinstrumentisintendedonlyforuseinsinglephaseoperation
at230V+10% -15%AC phasetoearth orfor useinOLD-TT
systemphasetoneutral.
● Iftheoverheatsymbolappearsinthedisplay( )disconnectthe
instrumentfromthemainssupplyandallowtocooldown.
● Whentestinginstallationthathasalargecurrentcapacity,suchas
apowerline,besurenottoshortliveconductorswiththetipofa
probe.Failuretofollowtheseinstructioncancausehazardstothe
user.
Fig.12
Pass the strap belt down
throughthe sidepanelofthe
mainbodyfromthetop,andup
throughtheslots of the probe
casefromthebottom.
Passthestrapthroughthe
buckle,adjustthestrapfor
lengthandsecure.
