CASE, STRAP AND SHOULDER-PAD ASSEMBLY
Correct assembly is shown in Fig 16. By hanging the instrument round the neck,
both hands will be left free for testing.
Fig16
① Pass the strap DOWN through
the first case lug,under the
case and UP through the other
lug.
② Side the sholder-pad onto
the strap.
③ Feed the strap DOWN through
the slots in the back of the
test-lead pouch.
④ Pass the strap through the
buckle,adjust the strap for
length and secure.
