L-ACOUSTICS ARCS Manual V2.0 2/13/2003 23
L-ACOUSTICS V7 0902 PRESETS for XTA DP 224
PRESET NAME PGM TYPE MEM OUT 1 (Source) OUT 2 (Source) OUT 3 (Source) OUT 4 (Source)
A
RCS 2W LO
2-way stereo 10 ARCS LO (A) ARCS HI (A) ARCS LO (B) ARCS HI (B)
A
RCS 2W HI
2-way stereo 11 ARCS LO (A) ARCS HI (A) ARCS LO (B) ARCS HI (B)
A
RCS 3W SB218 LO
3-way (A) + SUB (B) 12 SB218 (A) ARCS LO (A) ARCS HI (A) SB218 (B)
A
RCS 3W SB218 HI
3-way (A) + SUB (B) 13 SB218 (A) ARCS LO (A) ARCS HI (A) SB218 (B)
A
RCS 3W dVSUB LO
3-way (A) + SUB (B) 14 dV-SUB (A) ARCS LO (A) ARCS HI (A) dV-SUB (B)
A
RCS 3W dVSUB HI
3-way (A) + SUB (B) 15 dV-SUB (A) ARCS LO (A) ARCS HI (A) dV-SUB (B)
115FM 2W COUPLED
2-way stereo (not linked) 16 115FM LO (A) 115FM HI (A) 115FM LO (B) 115FM HI (B)
115FM 2WX SINGLE
2-way stereo (not linked) 17 115FM LO (A) 115FM HI (A) 115FM LO (B) 115FM HI (B)
115FM 3W SB115
3-way (A) + SUB (B) 18 SB115 (A) 115FM LO (A) 115FM HI (A) SB115 (B)
115FM 3W SB118
3-way (A) + SUB (B) 19 SB118 (A) 115FM LO (A) 115FM HI (A) SB118 (B)
115FM 3W SB218
3-way (A) + SUB (B) 20 SB218 (A) 115FM LO (A) 115FM HI (A) SB218 (B)
115FM 3W dV-SUB
3-way (A) + SUB (B) 21 dV-SUB (A) 115FM LO (A) 115FM HI (A) dV-SUB (B)
112XT 2W FILL
2-way stereo 22 112XT LO (A) 112XT HI (A) 112XT LO (B) 112XT HI (B)
112XT 2W FRONT
2-way stereo 23 112XT LO (A) 112XT HI (A) 112XT LO (B) 112XT HI (B)
112XT 2W MONITOR
2-way stereo (not linked) 24 112XT LO (A) 112XT HI (A) 112XT LO (B) 112XT HI (B)
112XT 3W SB115
3-way (A) + SUB (B) 25 SB115 (A) 112XT LO (A) 112XT HI (A) SB115 (B)
112XT 3WX SB115
3-way (A) + SUB (B) 26 SB115 (A) 112XT LO (A) 112XT HI (A) SB115 (B)
112XT 3W SB118
3-way (A) + SUB (B) 27 SB118 (A) 112XT LO (A) 112XT HI (A) SB118 (B)
112XT 3WX SB118
3-way (A) + SUB (B) 28 SB118 (A) 112XT LO (A) 112XT HI (A) SB118 (B)
112XT 3W SB218
3-way (A) + SUB (B) 29 SB218 (A) 112XT LO (A) 112XT HI (A) SB218 (B)
112XT 3WX SB218
3-way (A) + SUB (B) 30 SB218 (A) 112XT LO (A) 112XT HI (A) SB218 (B)
112XT 3W dV-SUB
3-way (A) + SUB (B) 31 dV-SUB (A) 112XT LO (A) 112XT HI (A) dV-SUB (B)
112XT 3WX dV-SUB
3-way (A) + SUB (B) 32 dV-SUB (A) 112XT LO (A) 112XT HI (A) dV-SUB (B)
115XT 2W FILL
2-way stereo 33 115XT LO (A) 115XT HI (A) 115XT LO (B) 115XT HI (B)
115XT 2W FRONT
2-way stereo 34 115XT LO (A) 115XT HI (A) 115XT LO (B) 115XT HI (B)
115XT 2W MONITOR
2-way stereo (not linked) 35 115XT LO (A) 115XT HI (A) 115XT LO (B) 115XT HI (B)
115XT 3W SB115
3-way (A) + SUB (B) 36 SB115 (A) 115XT LO (A) 115XT HI (A) SB115 (B)
115XT 3WX SB115
3-way (A) + SUB (B) 37 SB115 (A) 115XT LO (A) 115XT HI (A) SB115 (B)
115XT 3W SB118
3-way (A) + SUB (B) 38 SB118 (A) 115XT LO (A) 115XT HI (A) SB118 (B)
115XT 3WX SB118
3-way (A) + SUB (B) 39 SB118 (A) 115XT LO (A) 115XT HI (A) SB118 (B)
115XT 3W SB218
3-way (A) + SUB (B) 40 SB218 (A) 115XT LO (A) 115XT HI (A) SB218 (B)
115XT 3WX SB218
3-way (A) + SUB (B) 41 SB218 (A) 115XT LO (A) 115XT HI (A) SB218 (B)
115XT 3W dV-SUB
3-way (A) + SUB (B) 42 dV-SUB (A) 115XT LO (A) 115XT HI (A) dV-SUB (B)
115XT 3WX dV-SUB
3-way (A) + SUB (B) 43 dV-SUB (A) 115XT LO (A) 115XT HI (A) dV-SUB (B)
Table 6: XTA DP224 Presets
