L-ACOUSTICS ARCS Manual V2.0 2/13/2003 24
L-ACOUSTICS V7 0902 PRESETS for BSS 366 *
PRESET NAME PGM TYPE Mem OUT 1 (Source) OUT 2 (Source) OUT 3 (Source) OUT 4 (Source) OUT 5 (Source) OUT 6 (Source)
USE
R
3(A)+3(B) 1
ARCS 2W LO 3(A)+3(B) 2 FULL (A) ARCS LOW (A) ARCS HI (A) FULL (B) ARCS LOW (B) ARCS HI (B)
ARCS 2W HI 3(A)+3(B) 3 FULL (A) ARCS LOW (A) ARCS HI (A) FULL (B) ARCS LOW (B) ARCS HI (B)
ARC 218 L0 3(A)+3(B) 4 SB218 (A) ARCS LOW (A) ARCS HI (A) SB218 (B) ARCS LOW (B) ARCS HI (B)
ARC 218 HI 3(A)+3(B) 5 SB218 (A) ARCS LOW (A) ARCS HI (A) SB218 (B) ARCS LOW (B) ARCS HI (B)
ARC dVS LO 3(A)+3(B) 6 dV-SUB (A) ARCS LOW (A) ARCS HI (A) dV-SUB (B) ARCS LOW (B) ARCS HI (B)
ARC dVS HI 3(A)+3(B) 7 dV-SUB (A) ARCS LOW (A) ARCS HI (A) dV-SUB (B) ARCS LOW (B) ARCS HI (B)
115FM 2W 3(A)+3(B) 8 FULL (A) 115FM LOW (A) 115FM HI (A) FULL (B) 115FM LOW (B) 115FM HI (B)
115FM 2WX 3(A)+3(B) 9 FULL (A) 115FM LOW (A) 115FM HI (A) FULL (B) 115FM LOW (B) 115FM HI (B)
FM SB115 3(A)+3(B) 10 SB115 (A) 115FM LOW (A) 115FM HI (A) SB115 (B) 115FM LOW (B) 115FM HI (B)
FM SB118 3(A)+3(B) 11 SB118 (A) 115FM LOW (A) 115FM HI (A) SB118 (B) 115FM LOW (B) 115FM HI (B)
FM SB218 3(A)+3(B) 12 SB218 (A) 115FM LOW (A) 115FM HI (A) SB218 (B) 115FM LOW (B) 115FM HI (B)
FM dVSUB 3(A)+3(B) 13 dV-SUB (A) 115FM LOW (A) 115FM HI (A) dV-SUB (B) 115FM LOW (B) 115FM HI (B)
112XT FIL 3(A)+3(B) 14 FULL (A) 112XT LOW (A) 112XT HI (A) FULL (B) 112XT LOW (B) 112XT HI (B)
112XT FOH 3(A)+3(B) 15
FULL (A)
112XT LOW (A) 112XT HI (A)
FULL (B)
112XT LOW (B) 112XT HI (B)
112XT MON 3(A)+3(B) 16
FULL (A)
112XT LOW (A) 112XT HI (A)
FULL (B)
112XT LOW (B) 112XT HI (B)
112 SB115 3(A)+3(B) 17 SB115 (A) 112XT LOW (A) 112XT HI (A) SB115 (B) 112XT LOW (B) 112XT HI (B)
112 X 115 3(A)+3(B) 18 SB115 (A) 112XT LOW (A) 112XT HI (A) SB115 (B) 112XT LOW (B) 112XT HI (B)
112 SB118 3(A)+3(B) 19 SB118 (A) 112XT LOW (A) 112XT HI (A) SB118 (B) 112XT LOW (B) 112XT HI (B)
112 X 118 3(A)+3(B) 20 SB118 (A) 112XT LOW (A) 112XT HI (A) SB118 (B) 112XT LOW (B) 112XT HI (B)
112 SB218 3(A)+3(B) 21 SB218 (A) 112XT LOW (A) 112XT HI (A) SB218 (B) 112XT LOW (B) 112XT HI (B)
112 X 218 3(A)+3(B) 22 SB218 (A) 112XT LOW (A) 112XT HI (A) SB218 (B) 112XT LOW (B) 112XT HI (B)
112 dVS 3(A)+3(B) 23 dV-SUB (A) 112XT LOW (A) 112XT HI (A) dV-SUB (B) 112XT LOW (B) 112XT HI (B)
112 X dVS 3(A)+3(B) 24 dV-SUB (A) 112XT LOW (A) 112XT HI (A) dV-SUB (B) 112XT LOW (B) 112XT HI (B)
115XT FIL 3(A)+3(B) 25
FULL (A)
115XT LOW (A) 115XT HI (A)
FULL (B)
115XT LOW (B) 115XT HI (B)
115XT FOH 3(A)+3(B) 26
FULL (A)
115XT LOW (A) 115XT HI (A)
FULL (B)
115XT LOW (B) 115XT HI (B)
115XT MON 3(A)+3(B) 27 FULL (A) 115XT LOW (A) 115XT HI (A) FULL (B) 115XT LOW (B) 115XT HI (B)
115 SB115 3(A)+3(B) 28 SB115 (A) 115XT LOW (A) 115XT HI (A) SB115 (B) 115XT LOW (B) 115XT HI (B)
115 X 115 3(A)+3(B) 29 SB115 (A) 115XT LOW (A) 115XT HI (A) SB115 (B) 115XT LOW (B) 115XT HI (B)
115 SB118 3(A)+3(B) 30 SB118 (A) 115XT LOW (A) 115XT HI (A) SB118 (B) 115XT LOW (B) 115XT HI (B)
115 X 118 3(A)+3(B) 31 SB118 (A) 115XT LOW (A) 115XT HI (A) SB118 (B) 115XT LOW (B) 115XT HI (B)
115 SB218 3(A)+3(B) 32 SB218 (A) 115XT LOW (A) 115XT HI (A) SB218 (B) 115XT LOW (B) 115XT HI (B)
115 X 218 3(A)+3(B) 33 SB218 (A) 115XT LOW (A) 115XT HI (A) SB218 (B) 115XT LOW (B) 115XT HI (B)
115 dVS 3(A)+3(B) 34 dV-SUB (A) 115XT LOW (A) 115XT HI (A) dV-SUB (B) 115XT LOW (B) 115XT HI (B)
115 X dVS 3(A)+3(B) 35 dV-SUB (A) 115XT LOW (A) 115XT HI (A) dV-SUB (B) 115XT LOW (B) 115XT HI (B)
36 INTENTIONALLY BLANK (3 x 2-way presets follow)
ARCS 2W LO 2(A)+2(B)+2(C) 37 ARCS LOW (A) ARCS HI (A) ARCS LOW (B) ARCS HI (B) ARCS LOW (C) ARCS HI (C)
ARCS 2W HI 2(A)+2(B)+2(C) 38 ARCS LOW (A) ARCS HI (A) ARCS LOW (B) ARCS HI (B) ARCS LOW (C) ARCS HI (C)
115FM 2W 2(A)+2(B)+2(C) 39 115FM LOW (A) 115FM HI (A) 115FM LOW (B) 115FM HI (B) 115FM LOW (C) 115FM HI (C)
115FM 2WX 2(A)+2(B)+2(C) 40 115FM LOW (A) 115FM HI (A) 115FM LOW (B) 115FM HI (B) 115FM LOW (C) 115FM HI (C)
112XT FIL 2(A)+2(B)+2(C) 41 112XT LOW (A) 112XT HI (A) 112XT LOW (B) 112XT HI (B) 112XT LOW (C) 112XT HI (C)
112XT FOH 2(A)+2(B)+2(C) 42 112XT LOW (A) 112XT HI (A) 112XT LOW (B) 112XT HI (B) 112XT LOW (C) 112XT HI (C)
112XT MON 2(A)+2(B)+2(C) 43 112XT LOW (A) 112XT HI (A) 112XT LOW (B) 112XT HI (B) 112XT LOW (C) 112XT HI (C)
115XT FIL 2(A)+2(B)+2(C) 44 115XT LOW (A) 115XT HI (A) 115XT LOW (B) 115XT HI (B) 115XT LOW (C) 115XT HI (C)
115XT FOH 2(A)+2(B)+2(C) 45 115XT LOW (A) 115XT HI (A) 115XT LOW (B) 115XT HI (B) 115XT LOW (C) 115XT HI (C)
115XT MON 2(A)+2(B)+2(C) 46 115XT LOW (A) 115XT HI (A) 115XT LOW (B) 115XT HI (B) 115XT LOW (C) 115XT HI (C)
*L-ACOUSTICS V7 PRESETS MUST BE USED WITH BSS 366 VERSION 1.10 FIRMWARE (OR HIGHER)
Table 7: BSS 366 Omnidrive Compact Plus Presets
