System components
System components
Loudspeaker enclosures
L2 16-channel active progressive curvature WST 10° enclosure: 4 × 12" LC + 8 × 10" LF + 8 ×
3" HF
L2D 16-channel active progressive curvature WST 60° enclosure: 4 × 12" LC + 8 × 10" LF + 8 ×
3" HF
KS28 Flyable subwoofer 2 × 18"
Powering and driving system
LA7.16 / LA7.16i Amplied controller with DSP, preset library and networking capabilities
Refer to the LA7.16 / LA7.16i owner's manual for operating instructions.
Rack
LA-RAK III Touring rack containing three LA7.16, one LA-POWER II for power distribution, one LA-PANEL
III for audio signal distribution, and two LS10 for AVB distribution
Case
L-CASE II 2U electronics transport and protection case
Cables
SC32 cables 16-channel loudspeaker cables for touring application (37-point female connector to 37-point
male connector, 32 points used, 1.5 mm² gauge)
Come in different lengths: SC32-5 (5 m / 16.4 ft), SC32-10 (10 m / 32.8 ft), SC32-25 (25
m / 82 ft), SC32-50 (50 m / 164 ft)
SC32P 16-channel loudspeaker cable extension adaptor (37-point female connector to 37-point male
connector, 32 points used, without locking rings, 1.5 mm² gauge)
Length: 0.3 m / 1 ft
SC32 BE cables 16-channel loudspeaker cable for xed installation (37-point female connector to 32 bare end
cables for connection to a 16-channel amplied controller, 1.5 mm² gauge)
Come in different lengths: SC32-5 BE (5 m / 16.4 ft), SC32-10 BE (10 m / 32.8 ft)
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA7.16 / LA7.16i owner's manual for detailed instructions about the whole cabling scheme,
including modulation cables and network.
Rigging elements
L2-BUMP Flying frame for L2 and L2D (incl. 1 extension sling + 1 laser adapter)
L2-BAR Extension bar for L2-BUMP
L2-RIGBAR Rigging bar and pullback for L2 and L2D
LA-RAKMOUNT Mounting cradles for racks, including screws
BPCHAIN 1.5T Extension sling 1.5 tons (included in K3-BUMP)
K2-JACK 4 tilt adjustment screw jacks + 2 bars for chariots
L2-LASERMOUNT Lasermount for L2 and L2D
10 L2 owner's manual (EN) version 2.0
