Rigging system description
Rigging system description
L2/L2D
The L2 system includes two enclosures: L2 and L2D. Each enclosure can be own or stacked alone, or assembled into a
own array.
The coverage of the array is achieved by the 10° curvature of the L2 enclosures, while the 60° curvature of L2D is
designed to make it the last enclosure at the bottom of the array.
10°
60°
On both sides, L2/L2D integrate two arms to connect another element of the rigging system, such as an enclosure or a
ying frame.
• At the front, a rotating arm provides a xed point around which the enclosure can rotate until its connection at the
rear.
• At the rear, a sliding arm enables the inter-element rear connection.
L2 L2D
Adjacent enclosures or rigging accessories are secured by an automatic system with buttons and latches. The system is
activated in advance and locks itself during the lifting procedures.
