Rigging procedures
Flying an L2/L2D array with L2-RIGBAR
Type of deployment own array
Rigging accessories L2-RIGBAR
2 Ø19 mm shackles WLL 3.25 t
Min number of operators 2
Risk of falling objects
Verify that no unattached items remain on the product or assembly.
Additional safety for own arrays
When ying an array, use available holes to implement a secondary safety.
Prerequisite
Each L2/L2D is secured to its chariot. See Securing L2/L2D on L2-CHARIOT/L2D-CHARIOT (p.51).
Procedure
1. Secure L2-RIGBAR on top of the enclosure using the ball-locking pins.
Secure L2-RIGBAR at the front for a positive initial site angle, or at the back for a negative initial site angle.
70 L2 owner's manual (EN) version 2.0
