Rigging procedures
Dust
During the K2-JACK stabilizers rst use, dust comes off the threaded rod. It is expected and does not indicate
a malfunction.
2. Prepare the K2-JACK stabilizers.
Rotate the threaded rod counter-clockwise so the central part of the stabilizer is closest to the base.
3. Attach the stabilizers to the bar.
Insert the feet in the guides
at both ends of the bars.
Pivot the feet so they come
into contact with the bars.
Lock the feet into position by giving
a quarter-turn to the locking system.
L2 owner's manual (EN) version 2.0 75
