Corrective maintenance

D/R - Fin

Tools

• at plastic tool

• torque screwdriver

• T25 Torx bit

Repair kit

G03647

KR loudspeaker 10'' L2(D)

×6

S100228

M5x25 Torx

Exploded view

For safety reasons, always use the new screws and spare parts provided in the KR.

If no new screws are available, use blue threadlocker.

Use a at tool made of smooth plastic to avoid scratching the ns.

Use the at tool to unhook the n clips.

3 N.m

T25

L2 owner's manual (EN) version 2.0 97
