Rigging system description
A back plate, a top plate and a bottom plate conceal and protect the rigging elements and connectors when they are not
in use.
T30
3
N.m
T25
3
N.m
Always put the bottom plate screws back in place to avoid leaks.
Remove the bottom plate to stack Syva on Syva Low or Syva Base.
Syva
rigging
manual
(EN)
version
1.1
12
11
13
