Mechanical safety
Mechanical safety
Flown congurations
The Syva rigging system complies with 2006/42/EC: Machinery Directive. It has been designed following the guidelines
of BGV-C1.
2006/42/EC: Machinery Directive species a safety factor of 4 against the rupture. The own deployments described in
this manual achieve a safety factor of 5.
Refer to Soundvision for the safety factor of a specic deployment.
The safe limit gives the maximum number of elements for which the safety factor is always compliant with the
2006/42/EC: Machinery Directive, regardless of the other deployment parameters (site angles, inter-enclosure angles,
etc.)
The maximum limit gives the maximum number of elements for which the safety factor can be compliant with the
2006/42/EC: Machinery Directive, when the other deployment parameters provide the best mechanical conditions.
Syva
Conguration Rigging accessory Maximum / Safe limit
Flown Syva Bar 1
Wall-mounted Syva Wall 1
Other congurations
For other congurations, respect the recommended maximum limit for optimal stability.
Syva
Conguration Rigging accessory Maximum / Safe limit
Ground-stacked Syva Base 1
Pole-mounted Syva Pole 1
Syva Low / Syva Sub
Conguration Rigging accessory Maximum / Safe limit
Ground-stacked Syva Base 1
Ground-stacked No rigging accessory 1
Syva on Syva Low
Conguration Rigging accessory Maximum / Safe limit
Ground-stacked Syva Base 1
Mechanical safety of the rigging system
Before any installation, always model the system in Soundvision and check the Mechanical Data section for
any stress warning or stability warning.
9 Syva rigging manual (EN) version 1.1
