Rigging system description
Syva Bar
Syva Bar is a lifting bar for Syva.
linking points
Seven pickup points provide site angle settings between -10° and +5°.
+5°+2°0°-2°-5°-7.5°-10°
Syva Bar and Syva can be own with the provided Ø12 mm shackle WLL 1 t or secured to a structure with CLAMP250.
Syva rigging manual (EN) version 1.1 16
