L-Acoustics S Series User Manual

Loudspeaker congurations
< 60 cm / 24 in
Enclosures Syva Syva Low Syva Sub
Presets [SYVA LOW SYVA] [SYVA SUB_100]
Frequency range (-10 dB) 27 Hz - 20 kHz
Grouping subwoofers
Place the subwoofer enclosures side by side. If not possible, the maximum distance between two adjacent
acoustic centers must be 1.7m if the upper frequency limit of the subwoofer system is at 100Hz.
Do not forget to add the geometric delays depending on the conguration.
No pre-alignment delay values are required for the Syva system.
Syva owner's manual (EN) version 1.0 29
